Triple Clamp Pinch Bolt and Washer Set for Big Twin 1936-Up
Early Springer Hardware Depth — Every early springer part and chassis hardware piece is checked against specific platform families and year ranges before quotation, ensuring exact triple clamp fitment for classic Big Twin restorations.
Product Specification
| Parameter | Value |
|---|---|
| OEM Reference | 4729 (reference only) |
| Part Type | Triple Clamp Pinch Bolt and Washer Set |
| Finish | Chrome Plated |
| Head Type | Allen Head |
| Kit Contents | Bolt and Washer Set |
Fitment
| Platform | Year Range | Notes |
|---|---|---|
| Big Twin | 1936-up | Verify exact model year and configuration |
| 45ci | 1940-up | Thread length differs from later setups |
| FLT | Excluded | Does not fit FLT models |
| Deuce | Excluded | Does not fit Deuce models |
