Chrome 18″ Springer Fork Assembly – Fitment Checked
Dimension-Verified Front End Sourcing — Every 18″ narrow springer fork assembly is measured against frame neck specs before dispatch to guarantee exact stem and rocker alignment.
Product Specification
| Parameter | Value |
|---|---|
| Part Type | Springer Fork Assembly |
| Finish | Chrome |
| Overall Length | 18″ |
| Stem Diameter | 1″ |
| Axle Outer Diameter | 3/4″ |
| Width Between Rockers | 6″ |
| Leg Thread | 3/4″-18 |
| Kit Contents | Triple tree, stem, brake boss, axle, original-style fittings |
Fitment
| Platform | Year Range | Notes |
|---|---|---|
| Custom Frames | Confirm with model and year | Accepts standard springer handlebars; left side rocker is offset for brake system clearance. |
